#include "tmqh-packetpool.h"
#include "tm-threads-common.h"
#include "tm-modules.h"
#include "flow.h"

Include dependency graph for tm-threads.h:

Data Structures
struct	TmSlot_

Macros
#define	SleepUsec(usec) usleep((usec))

#define	SleepMsec(msec) usleep((msec) * 1000)

#define	TM_QUEUE_NAME_MAX 16

#define	TM_THREAD_NAME_MAX 16

Typedefs
typedef TmEcode(*	TmSlotFunc) (ThreadVars , Packet , void *)

typedef struct TmSlot_	TmSlot

Functions
void	TmSlotSetFuncAppend (ThreadVars , TmModule , const void *)
	Appends a new entry to the slots. More...

ThreadVars *	TmThreadCreate (const char , const char , const char , const char , const char , const char , void (fn_p)(void ), int)

ThreadVars *	TmThreadCreatePacketHandler (const char , const char , const char , const char , const char , const char )
	Creates and returns a TV instance for a Packet Processing Thread. This function doesn't support custom slots, and hence shouldn't be supplied "custom" as its slot type. All PPT threads are created with a mucond(see TmThreadCreate declaration) of 0. Hence the tv conditional variables are not used to kill the thread. More...

ThreadVars *	TmThreadCreateMgmtThread (const char name, void (fn_p)(void *), int)
	Creates and returns the TV instance for a Management thread(MGMT). This function supports only custom slot functions and hence a function pointer should be sent as an argument. More...

ThreadVars *	TmThreadCreateMgmtThreadByName (const char name, const char module, int mucond)
	Creates and returns the TV instance for a Management thread(MGMT). This function supports only custom slot functions and hence a function pointer should be sent as an argument. More...

ThreadVars *	TmThreadCreateCmdThreadByName (const char name, const char module, int mucond)
	Creates and returns the TV instance for a Command thread (CMD). This function supports only custom slot functions and hence a function pointer should be sent as an argument. More...

TmEcode	TmThreadSpawn (ThreadVars *)
	Spawns a thread associated with the ThreadVars instance tv. More...

void	TmThreadKillThreadsFamily (int family)

void	TmThreadKillThreads (void)

void	TmThreadClearThreadsFamily (int family)

void	TmThreadAppend (ThreadVars *, int)
	Appends this TV to tv_root based on its type. More...

void	TmThreadSetGroupName (ThreadVars tv, const char name)

TmEcode	TmThreadSetCPUAffinity (ThreadVars *, uint16_t)
	Set the thread options (cpu affinity). More...

TmEcode	TmThreadSetThreadPriority (ThreadVars *, int)
	Set the thread options (thread priority). More...

TmEcode	TmThreadSetCPU (ThreadVars *, uint8_t)

TmEcode	TmThreadSetupOptions (ThreadVars *)
	Set the thread options (cpu affinitythread). Priority should be already set by pthread_create. More...

void	TmThreadSetPrio (ThreadVars *)
	Adjusting nice value for threads. More...

int	TmThreadGetNbThreads (uint8_t type)

void	TmThreadInitMC (ThreadVars *)
	Initializes the mutex and condition variables for this TV. More...

void	TmThreadContinue (ThreadVars *)
	Unpauses a thread. More...

void	TmThreadContinueThreads (void)
	Unpauses all threads present in tv_root. More...

void	TmThreadCheckThreadState (void)
	Used to check the thread for certain conditions of failure. More...

TmEcode	TmThreadWaitOnThreadInit (void)
	Used to check if all threads have finished their initialization. On finding an un-initialized thread, it waits till that thread completes its initialization, before proceeding to the next thread. More...

int	TmThreadsCheckFlag (ThreadVars *, uint32_t)
	Check if a thread flag is set. More...

void	TmThreadsSetFlag (ThreadVars *, uint32_t)
	Set a thread flag. More...

void	TmThreadsUnsetFlag (ThreadVars *, uint32_t)
	Unset a thread flag. More...

void	TmThreadWaitForFlag (ThreadVars *, uint32_t)
	Waits till the specified flag(s) is(are) set. We don't bother if the kill flag has been set or not on the thread. More...

TmEcode	TmThreadsSlotVarRun (ThreadVars tv, Packet p, TmSlot *slot)
	Separate run function so we can call it recursively. More...

void	TmThreadDisablePacketThreads (void)
	Disable all packet threads. More...

void	TmThreadDisableReceiveThreads (void)
	Disable all threads having the specified TMs. More...

uint32_t	TmThreadCountThreadsByTmmFlags (uint8_t flags)
	returns a count of all the threads that match the flag More...

TmEcode	TmThreadWaitOnThreadRunning (void)
	Waits for all threads to be in a running state. More...

TmEcode	TmThreadsProcessDecodePseudoPackets (ThreadVars tv, PacketQueueNoLock decode_pq, TmSlot *slot)

void	TmThreadsListThreads (void)

int	TmThreadsRegisterThread (ThreadVars *tv, const int type)

void	TmThreadsUnregisterThread (const int id)

void	TmThreadsInjectFlowById (Flow *f, const int id)
	inject a flow into a threads flow queue More...

void	TmThreadsInitThreadsTimestamp (const SCTime_t ts)

void	TmThreadsSetThreadTimestamp (const int id, const SCTime_t ts)

void	TmThreadsGetMinimalTimestamp (struct timeval *ts)

uint16_t	TmThreadsGetWorkerThreadMax (void)

bool	TmThreadsTimeSubsysIsReady (void)

bool	TmThreadsWaitForUnpause (ThreadVars *tv)
	Wait for a thread to become unpaused. More...

Variables
ThreadVars *	tv_root [TVT_MAX]

SCMutex	tv_root_lock

Detailed Description

Author: Victor Julien victo.nosp@m.r@in.nosp@m.linia.nosp@m.c.ne.nosp@m.t; Anoop Saldanha anoop.nosp@m.sald.nosp@m.anha@.nosp@m.gmai.nosp@m.l.com

Definition in file tm-threads.h.

Macro Definition Documentation

◆ SleepMsec

#define SleepMsec ( msec ) usleep((msec) * 1000)

Definition at line 46 of file tm-threads.h.

◆ SleepUsec

#define SleepUsec ( usec ) usleep((usec))

Definition at line 45 of file tm-threads.h.

◆ TM_QUEUE_NAME_MAX

#define TM_QUEUE_NAME_MAX 16

Definition at line 49 of file tm-threads.h.

◆ TM_THREAD_NAME_MAX

#define TM_THREAD_NAME_MAX 16

Definition at line 50 of file tm-threads.h.

Typedef Documentation

◆ TmSlot

typedef struct TmSlot_ TmSlot

◆ TmSlotFunc

typedef TmEcode(* TmSlotFunc) (ThreadVars *, Packet *, void *)

Definition at line 51 of file tm-threads.h.

Function Documentation

◆ TmSlotSetFuncAppend()

void TmSlotSetFuncAppend	(	ThreadVars *	tv,
		TmModule *	tm,
		const void *	data
	)

Appends a new entry to the slots.

Parameters

tv	TV the slot is attached to.
tm	TM to append.
data	Data to be passed on to the slot init function.

Return values

The	allocated TmSlot or NULL if there is an error

Definition at line 649 of file tm-threads.c.

References ThreadVars_::break_loop, TmModule_::cap_flags, ThreadVars_::cap_flags, TmModule_::flags, TmModule_::Func, TmSlot_::Management, TmModule_::Management, TmModule_::PktAcqBreakLoop, TmModule_::PktAcqLoop, TmSlot_::PktAcqLoop, SC_ATOMIC_INITPTR, SCCalloc, TmSlot_::slot_initdata, TmSlot_::slot_next, TmSlot_::SlotFunc, TmSlot_::SlotThreadDeinit, TmSlot_::SlotThreadExitPrintStats, TmSlot_::SlotThreadInit, TmModule_::ThreadDeinit, TmModule_::ThreadExitPrintStats, TmModule_::ThreadInit, TmSlot_::tm_flags, TmSlot_::tm_id, ThreadVars_::tm_slots, ThreadVars_::tmm_flags, TmModuleGetIDForTM(), tv, and unlikely.

Referenced by RunModeErfFileAutoFp(), RunModeErfFileSingle(), RunModeFilePcapAutoFp(), RunModeFilePcapSingle(), RunModeSetIPSAutoFp(), RunModeSetIPSWorker(), RunModeSetLiveCaptureAutoFp(), TmThreadCreateCmdThreadByName(), and TmThreadCreateMgmtThreadByName().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadAppend()

void TmThreadAppend	(	ThreadVars *	tv,
		int	type
	)

Appends this TV to tv_root based on its type.

Parameters

type	holds the type this TV belongs to.

Definition at line 1160 of file tm-threads.c.

References ThreadVars_::next, SCMutexLock, SCMutexUnlock, tv, tv_root, tv_root_lock, and type.

Referenced by TmThreadSpawn().

Here is the caller graph for this function:

◆ TmThreadCheckThreadState()

void TmThreadCheckThreadState ( void )

Used to check the thread for certain conditions of failure.

Definition at line 1924 of file tm-threads.c.

References FatalError, ThreadVars_::name, ThreadVars_::next, SCMutexLock, SCMutexUnlock, THV_FAILED, TmThreadsCheckFlag(), tv, tv_root, tv_root_lock, and TVT_MAX.

Referenced by SuricataMainLoop().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadClearThreadsFamily()

void TmThreadClearThreadsFamily ( int family )

Definition at line 1638 of file tm-threads.c.

References ThreadVars_::next, SCMutexLock, tv, tv_root, tv_root_lock, and TVT_MAX.

◆ TmThreadContinue()

void TmThreadContinue ( ThreadVars * tv )

Unpauses a thread.

Parameters

tv	Pointer to a TV instance that has to be unpaused

Definition at line 1772 of file tm-threads.c.

References THV_PAUSE, TmThreadsUnsetFlag(), and tv.

Referenced by TmThreadContinueDetectLoaderThreads(), and TmThreadContinueThreads().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadContinueThreads()

void TmThreadContinueThreads ( void )

Unpauses all threads present in tv_root.

Definition at line 1908 of file tm-threads.c.

References ThreadVars_::next, SCMutexLock, SCMutexUnlock, TmThreadContinue(), tv, tv_root, tv_root_lock, and TVT_MAX.

Referenced by SuricataPostInit().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadCountThreadsByTmmFlags()

uint32_t TmThreadCountThreadsByTmmFlags ( uint8_t flags )

returns a count of all the threads that match the flag

Definition at line 2010 of file tm-threads.c.

References cnt, flags, ThreadVars_::next, SCMutexLock, SCMutexUnlock, ThreadVars_::tmm_flags, tv, tv_root, tv_root_lock, and TVT_MAX.

Referenced by PacketPoolPostRunmodes().

Here is the caller graph for this function:

◆ TmThreadCreate()

ThreadVars* TmThreadCreate	(	const char *	,
		const char *	,
		const char *	,
		const char *	,
		const char *	,
		const char *	,
		void *	fn_p)(void *,
		int
	)

◆ TmThreadCreateCmdThreadByName()

ThreadVars* TmThreadCreateCmdThreadByName	(	const char *	name,
		const char *	module,
		int	mucond
	)

Creates and returns the TV instance for a Command thread (CMD). This function supports only custom slot functions and hence a function pointer should be sent as an argument.

Parameters

name	Name of this TV instance
module	Name of TmModule with COMMAND flag set.
mucond	Flag to indicate whether to initialize the condition and the mutex variables for this newly created TV.

Return values

the	newly created TV instance, or NULL on error

Definition at line 1134 of file tm-threads.c.

References ThreadVars_::id, m, MANAGEMENT_CPU_SET, TmModuleGetByName(), TmSlotSetFuncAppend(), TmThreadCreate(), TmThreadSetCPU(), TmThreadsRegisterThread(), tv, TVT_CMD, and ThreadVars_::type.

Here is the call graph for this function:

◆ TmThreadCreateMgmtThread()

ThreadVars* TmThreadCreateMgmtThread	(	const char *	name,
		void *	fn_p)(void *,
		int	mucond
	)

Creates and returns the TV instance for a Management thread(MGMT). This function supports only custom slot functions and hence a function pointer should be sent as an argument.

Parameters

name	Name of this TV instance
fn_p	Pointer to function when "slots" is of type "custom"
mucond	Flag to indicate whether to initialize the condition and the mutex variables for this newly created TV.

Return values

the	newly created TV instance, or NULL on error

Definition at line 1073 of file tm-threads.c.

References ThreadVars_::id, MANAGEMENT_CPU_SET, TmThreadCreate(), TmThreadSetCPU(), TmThreadsRegisterThread(), tv, TVT_MGMT, and ThreadVars_::type.

Here is the call graph for this function:

◆ TmThreadCreateMgmtThreadByName()

ThreadVars* TmThreadCreateMgmtThreadByName	(	const char *	name,
		const char *	module,
		int	mucond
	)

Creates and returns the TV instance for a Management thread(MGMT). This function supports only custom slot functions and hence a function pointer should be sent as an argument.

Parameters

name	Name of this TV instance
module	Name of TmModule with MANAGEMENT flag set.
mucond	Flag to indicate whether to initialize the condition and the mutex variables for this newly created TV.

Return values

the	newly created TV instance, or NULL on error

Definition at line 1101 of file tm-threads.c.

References ThreadVars_::id, m, MANAGEMENT_CPU_SET, TmModuleGetByName(), TmSlotSetFuncAppend(), TmThreadCreate(), TmThreadSetCPU(), TmThreadsRegisterThread(), tv, TVT_MGMT, and ThreadVars_::type.

Referenced by BypassedFlowManagerThreadSpawn().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadCreatePacketHandler()

ThreadVars* TmThreadCreatePacketHandler	(	const char *	name,
		const char *	inq_name,
		const char *	inqh_name,
		const char *	outq_name,
		const char *	outqh_name,
		const char *	slots
	)

Creates and returns a TV instance for a Packet Processing Thread. This function doesn't support custom slots, and hence shouldn't be supplied "custom" as its slot type. All PPT threads are created with a mucond(see TmThreadCreate declaration) of 0. Hence the tv conditional variables are not used to kill the thread.

Parameters

name	Name of this TV instance
inq_name	Incoming queue name
inqh_name	Incoming queue handler name as set by TmqhSetup()
outq_name	Outgoing queue name
outqh_name	Outgoing queue handler as set by TmqhSetup()
slots	String representation for the slot function to be used

Return values

the	newly created TV instance, or NULL on error

Definition at line 1044 of file tm-threads.c.

References ThreadVars_::id, TmThreadCreate(), TmThreadsRegisterThread(), tv, TVT_PPT, and ThreadVars_::type.

Referenced by RunModeErfFileAutoFp(), RunModeErfFileSingle(), RunModeFilePcapAutoFp(), RunModeFilePcapSingle(), RunModeSetIPSAutoFp(), RunModeSetIPSWorker(), and RunModeSetLiveCaptureAutoFp().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadDisablePacketThreads()

void TmThreadDisablePacketThreads ( void )

Disable all packet threads.

Definition at line 1487 of file tm-threads.c.

Referenced by PostRunDeinit().

Here is the caller graph for this function:

◆ TmThreadDisableReceiveThreads()

void TmThreadDisableReceiveThreads ( void )

Disable all threads having the specified TMs.

Breaks out of the packet acquisition loop, and bumps into the 'flow loop', where it will process packets from the flow engine's shutdown handling.

Definition at line 1358 of file tm-threads.c.

References FatalError, TmModule_::flags, ThreadVars_::name, SCMutexLock, TmSlot_::slot_next, TM_FLAG_RECEIVE_TM, TmSlot_::tm_id, ThreadVars_::tm_slots, TmModuleGetById(), tv, tv_root, tv_root_lock, and TVT_PPT.

Referenced by PostRunDeinit().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadGetNbThreads()

int TmThreadGetNbThreads ( uint8_t type )

Definition at line 838 of file tm-threads.c.

References MAX_CPU_SET, ThreadsAffinityType_::nb_threads, SCLogError, thread_affinity, and type.

Referenced by RunModeErfFileAutoFp(), RunModeFilePcapAutoFp(), and TmThreadsGetWorkerThreadMax().

Here is the caller graph for this function:

◆ TmThreadInitMC()

void TmThreadInitMC ( ThreadVars * tv )

Initializes the mutex and condition variables for this TV.

It can be used by a thread to control a wait loop that can also be influenced by other threads.

Parameters

tv	Pointer to a TV instance

Definition at line 1719 of file tm-threads.c.

References ThreadVars_::ctrl_cond, ThreadVars_::ctrl_mutex, FatalError, SCCtrlCondInit, SCCtrlMutexInit, SCMalloc, and tv.

◆ TmThreadKillThreads()

void TmThreadKillThreads ( void )

Definition at line 1566 of file tm-threads.c.

References TmThreadKillThreadsFamily(), and TVT_MAX.

Referenced by SuricataShutdown().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadKillThreadsFamily()

void TmThreadKillThreadsFamily ( int family )

Definition at line 1537 of file tm-threads.c.

References BUG_ON, MIN_WAIT_TIME, SCMutexLock, tv, tv_root, tv_root_lock, and TVT_MAX.

Referenced by TmThreadKillThreads().

Here is the caller graph for this function:

◆ TmThreadsCheckFlag()

int TmThreadsCheckFlag	(	ThreadVars *	tv,
		uint32_t	flag
	)

Check if a thread flag is set.

Return values

1	flag is set.
0	flag is not set.

Definition at line 93 of file tm-threads.c.

References SC_ATOMIC_GET, and tv.

Referenced by FlowDisableFlowManagerThread(), TmThreadCheckThreadState(), TmThreadsWaitForUnpause(), TmThreadWaitForFlag(), and TmThreadWaitOnThreadInit().

Here is the caller graph for this function:

◆ TmThreadSetCPU()

TmEcode TmThreadSetCPU	(	ThreadVars *	,
		uint8_t
	)

Definition at line 822 of file tm-threads.c.

References ThreadVars_::cpu_affinity, MAX_CPU_SET, SCLogError, THREAD_SET_AFFTYPE, ThreadVars_::thread_setup_flags, threading_set_cpu_affinity, TM_ECODE_FAILED, TM_ECODE_OK, tv, and type.

Referenced by RunModeFilePcapAutoFp(), RunModeFilePcapSingle(), RunModeSetIPSAutoFp(), RunModeSetIPSWorker(), RunModeSetLiveCaptureAutoFp(), TmThreadCreateCmdThreadByName(), TmThreadCreateMgmtThread(), and TmThreadCreateMgmtThreadByName().

Here is the caller graph for this function:

◆ TmThreadSetCPUAffinity()

TmEcode TmThreadSetCPUAffinity	(	ThreadVars *	tv,
		uint16_t	cpu
	)

Set the thread options (cpu affinity).

Parameters

tv	pointer to the ThreadVars to setup the affinity.
cpu	cpu on which affinity is set.

Return values

TM_ECODE_OK

Definition at line 813 of file tm-threads.c.

References ThreadVars_::cpu_affinity, THREAD_SET_AFFINITY, ThreadVars_::thread_setup_flags, TM_ECODE_OK, and tv.

Referenced by RunModeErfFileAutoFp().

Here is the caller graph for this function:

◆ TmThreadSetGroupName()

void TmThreadSetGroupName	(	ThreadVars *	tv,
		const char *	name
	)

Definition at line 1620 of file tm-threads.c.

References SCLogError, SCStrdup, ThreadVars_::thread_group_name, tv, and unlikely.

Referenced by RunModeErfFileAutoFp(), RunModeFilePcapAutoFp(), RunModeSetIPSAutoFp(), and RunModeSetLiveCaptureAutoFp().

Here is the caller graph for this function:

◆ TmThreadSetPrio()

void TmThreadSetPrio ( ThreadVars * )

Adjusting nice value for threads.

Definition at line 776 of file tm-threads.c.

References ThreadVars_::name, SCEnter, SCLogDebug, SCLogError, SCReturn, ThreadVars_::thread_priority, and tv.

◆ TmThreadSetThreadPriority()

TmEcode TmThreadSetThreadPriority	(	ThreadVars *	tv,
		int	prio
	)

Set the thread options (thread priority).

Parameters

tv	Pointer to the ThreadVars to setup the thread priority.

Return values

TM_ECODE_OK.

Definition at line 765 of file tm-threads.c.

References ThreadVars_::thread_priority, THREAD_SET_PRIORITY, ThreadVars_::thread_setup_flags, TM_ECODE_OK, and tv.

Referenced by RunModeErfFileAutoFp().

Here is the caller graph for this function:

◆ TmThreadSetupOptions()

TmEcode TmThreadSetupOptions ( ThreadVars * tv )

Set the thread options (cpu affinitythread). Priority should be already set by pthread_create.

Parameters

tv	pointer to the ThreadVars of the calling thread.

Definition at line 854 of file tm-threads.c.

References ThreadVars_::cpu_affinity, ThreadVars_::name, SCGetThreadIdLong, SCLogPerf, THREAD_SET_AFFINITY, ThreadVars_::thread_setup_flags, and tv.

◆ TmThreadsGetMinimalTimestamp()

void TmThreadsGetMinimalTimestamp ( struct timeval * ts )

Definition at line 2250 of file tm-threads.c.

References SCTIME_INITIALIZER.

◆ TmThreadsGetWorkerThreadMax()

uint16_t TmThreadsGetWorkerThreadMax ( void )

Definition at line 2287 of file tm-threads.c.

References SCLogWarning, threading_detect_ratio, TmThreadGetNbThreads(), UtilCpuGetNumProcessorsOnline(), and WORKER_CPU_SET.

Referenced by RunModeSetIPSAutoFp(), and RunModeSetLiveCaptureAutoFp().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadsInitThreadsTimestamp()

void TmThreadsInitThreadsTimestamp ( const SCTime_t ts )

Definition at line 2234 of file tm-threads.c.

Referenced by PcapFileDispatch().

Here is the caller graph for this function:

◆ TmThreadsInjectFlowById()

void TmThreadsInjectFlowById	(	Flow *	f,
		const int	id
	)

inject a flow into a threads flow queue

Definition at line 2305 of file tm-threads.c.

References BUG_ON.

Referenced by FlowSendToLocalThread().

Here is the caller graph for this function:

◆ TmThreadsListThreads()

void TmThreadsListThreads ( void )

Definition at line 2088 of file tm-threads.c.

References SCMutexLock.

◆ TmThreadSpawn()

TmEcode TmThreadSpawn ( ThreadVars * tv )

Spawns a thread associated with the ThreadVars instance tv.

Return values

TM_ECODE_OK on success and TM_ECODE_FAILED on failure

Definition at line 1663 of file tm-threads.c.

References FatalError, SCLogDebug, ThreadVars_::t, threading_set_stack_size, THV_INIT_DONE, THV_RUNNING_DONE, TM_ECODE_OK, ThreadVars_::tm_func, TmThreadAppend(), TmThreadWaitForFlag(), tv, and ThreadVars_::type.

Referenced by BypassedFlowManagerThreadSpawn(), RunModeErfFileAutoFp(), RunModeErfFileSingle(), RunModeFilePcapAutoFp(), RunModeFilePcapSingle(), RunModeSetIPSAutoFp(), RunModeSetIPSWorker(), and RunModeSetLiveCaptureAutoFp().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadsProcessDecodePseudoPackets()

TmEcode TmThreadsProcessDecodePseudoPackets	(	ThreadVars *	tv,
		PacketQueueNoLock *	decode_pq,
		TmSlot *	slot
	)

Definition at line 114 of file tm-threads.c.

References DEBUG_VALIDATE_BUG_ON, Packet_::flow, PacketDequeueNoLock(), PacketQueueNoLock_::top, and unlikely.

Here is the call graph for this function:

◆ TmThreadsRegisterThread()

int TmThreadsRegisterThread	(	ThreadVars *	tv,
		const int	type
	)

Return values

id	thread id, or 0 if not found

Definition at line 2112 of file tm-threads.c.

References SCMutexLock.

Referenced by TmThreadCreateCmdThreadByName(), TmThreadCreateMgmtThread(), TmThreadCreateMgmtThreadByName(), and TmThreadCreatePacketHandler().

Here is the caller graph for this function:

◆ TmThreadsSetFlag()

void TmThreadsSetFlag	(	ThreadVars *	,
		uint32_t
	)

Set a thread flag.

Definition at line 101 of file tm-threads.c.

References SC_ATOMIC_OR, and tv.

Referenced by FlowDisableFlowManagerThread(), ReceiveErfDagLoop(), ReceiveErfFileLoop(), TmThreadCreate(), and TmThreadsWaitForUnpause().

Here is the caller graph for this function:

◆ TmThreadsSetThreadTimestamp()

void TmThreadsSetThreadTimestamp	(	const int	id,
		const SCTime_t	ts
	)

Definition at line 2188 of file tm-threads.c.

References SCMutexLock.

◆ TmThreadsSlotVarRun()

TmEcode TmThreadsSlotVarRun	(	ThreadVars *	tv,
		Packet *	p,
		TmSlot *	slot
	)

Separate run function so we can call it recursively.

Definition at line 133 of file tm-threads.c.

References DEBUG_VALIDATE_BUG_ON, Packet_::flow, PACKET_PROFILING_TMM_END, PACKET_PROFILING_TMM_START, SC_ATOMIC_GET, TmSlot_::slot_next, TM_ECODE_FAILED, tv, and unlikely.

◆ TmThreadsTimeSubsysIsReady()

bool TmThreadsTimeSubsysIsReady ( void )

Definition at line 2214 of file tm-threads.c.

References SCMutexLock, and SCTIME_INITIALIZER.

◆ TmThreadsUnregisterThread()

void TmThreadsUnregisterThread ( const int id )

Definition at line 2155 of file tm-threads.c.

References SCMutexLock.

◆ TmThreadsUnsetFlag()

void TmThreadsUnsetFlag	(	ThreadVars *	,
		uint32_t
	)

Unset a thread flag.

Definition at line 109 of file tm-threads.c.

References SC_ATOMIC_AND, and tv.

Referenced by TmThreadContinue(), and TmThreadsWaitForUnpause().

Here is the caller graph for this function:

◆ TmThreadsWaitForUnpause()

bool TmThreadsWaitForUnpause ( ThreadVars * tv )

Wait for a thread to become unpaused.

Check if a thread should wait to be unpaused and wait if so, or until the thread kill flag is set.

Returns: true if the thread was unpaused, false if killed.

Also returns if the kill flag is set.

Definition at line 364 of file tm-threads.c.

References SleepUsec, THV_KILL, THV_PAUSE, THV_PAUSED, TmThreadsCheckFlag(), TmThreadsSetFlag(), TmThreadsUnsetFlag(), and tv.

Here is the call graph for this function:

◆ TmThreadWaitForFlag()

void TmThreadWaitForFlag	(	ThreadVars *	tv,
		uint32_t	flags
	)

Waits till the specified flag(s) is(are) set. We don't bother if the kill flag has been set or not on the thread.

Parameters

tv	Pointer to the TV instance.

Definition at line 1760 of file tm-threads.c.

References flags, SleepUsec, TmThreadsCheckFlag(), and tv.

Referenced by TmThreadSpawn().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadWaitOnThreadInit()

TmEcode TmThreadWaitOnThreadInit ( void )

Used to check if all threads have finished their initialization. On finding an un-initialized thread, it waits till that thread completes its initialization, before proceeding to the next thread.

Return values

TM_ECODE_OK	all initialized properly
TM_ECODE_FAILED	failure

Definition at line 1947 of file tm-threads.c.

References ThreadVars_::name, ThreadVars_::next, SC_ATOMIC_GET, SCLogError, SCMutexLock, SCMutexUnlock, SleepUsec, THV_CLOSED, THV_DEAD, THV_FAILED, THV_INIT_DONE, TM_ECODE_FAILED, TM_ECODE_OK, TmThreadsCheckFlag(), tv, tv_root, tv_root_lock, and TVT_MAX.

Referenced by SuricataPostInit().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TmThreadWaitOnThreadRunning()

TmEcode TmThreadWaitOnThreadRunning ( void )

Waits for all threads to be in a running state.

Return values

TM_ECODE_OK if all are running or error if a thread failed

Definition at line 1839 of file tm-threads.c.

References TVT_MAX.

Referenced by SuricataPostInit().

Here is the caller graph for this function:

Variable Documentation

◆ tv_root

ThreadVars* tv_root[TVT_MAX]

Definition at line 82 of file tm-threads.c.

Referenced by FlowDisableFlowManagerThread(), TmThreadAppend(), TmThreadCheckThreadState(), TmThreadClearThreadsFamily(), TmThreadContinueDetectLoaderThreads(), TmThreadContinueThreads(), TmThreadCountThreadsByTmmFlags(), TmThreadDisableReceiveThreads(), TmThreadKillThreadsFamily(), and TmThreadWaitOnThreadInit().

◆ tv_root_lock

SCMutex tv_root_lock

Definition at line 85 of file tm-threads.c.

Referenced by FlowDisableFlowManagerThread(), TmThreadAppend(), TmThreadCheckThreadState(), TmThreadClearThreadsFamily(), TmThreadContinueDetectLoaderThreads(), TmThreadContinueThreads(), TmThreadCountThreadsByTmmFlags(), TmThreadDisableReceiveThreads(), TmThreadKillThreadsFamily(), and TmThreadWaitOnThreadInit().

Data Structures

Macros

Typedefs

Functions

Variables

Detailed Description

Macro Definition Documentation

◆ SleepMsec

◆ SleepUsec

◆ TM_QUEUE_NAME_MAX

◆ TM_THREAD_NAME_MAX

Typedef Documentation

◆ TmSlot

◆ TmSlotFunc

Function Documentation

◆ TmSlotSetFuncAppend()

◆ TmThreadAppend()

◆ TmThreadCheckThreadState()

◆ TmThreadClearThreadsFamily()

◆ TmThreadContinue()

◆ TmThreadContinueThreads()

◆ TmThreadCountThreadsByTmmFlags()

◆ TmThreadCreate()

◆ TmThreadCreateCmdThreadByName()

◆ TmThreadCreateMgmtThread()

◆ TmThreadCreateMgmtThreadByName()

◆ TmThreadCreatePacketHandler()

◆ TmThreadDisablePacketThreads()

◆ TmThreadDisableReceiveThreads()

◆ TmThreadGetNbThreads()

◆ TmThreadInitMC()

◆ TmThreadKillThreads()

◆ TmThreadKillThreadsFamily()

◆ TmThreadsCheckFlag()

◆ TmThreadSetCPU()

◆ TmThreadSetCPUAffinity()

◆ TmThreadSetGroupName()

◆ TmThreadSetPrio()

◆ TmThreadSetThreadPriority()

◆ TmThreadSetupOptions()

◆ TmThreadsGetMinimalTimestamp()

◆ TmThreadsGetWorkerThreadMax()

◆ TmThreadsInitThreadsTimestamp()

◆ TmThreadsInjectFlowById()

◆ TmThreadsListThreads()

◆ TmThreadSpawn()

◆ TmThreadsProcessDecodePseudoPackets()

◆ TmThreadsRegisterThread()

◆ TmThreadsSetFlag()

◆ TmThreadsSetThreadTimestamp()

◆ TmThreadsSlotVarRun()

◆ TmThreadsTimeSubsysIsReady()

◆ TmThreadsUnregisterThread()

◆ TmThreadsUnsetFlag()

◆ TmThreadsWaitForUnpause()

◆ TmThreadWaitForFlag()

◆ TmThreadWaitOnThreadInit()

◆ TmThreadWaitOnThreadRunning()

Variable Documentation

◆ tv_root

◆ tv_root_lock
